High-Efficiency asynchronous motor for pool pump MYT Series
High-Efficiency asynchronous motor for pool pump MYT Series
Products Details:
其他信息
| Brand | ZOZHI |
|---|---|
| Products Name | OPHS Series Motors |
| Country of Origin | Fujian China |
| Certification | ISO,CE,CCC |
High-Efficiency asynchronous motor for pool pump MYT Series
MYT series high efficiency single-phase capacitor-run asynchronous aluminum housing motor, Designed for swimming pool pump, spa pump, and bath pump, with the latest design in entirety is made of selected quality materials and conform to the IEC standard.
MYT motors have high efficiency, good performance, safety, and reliable operation, nice appearance and can be maintained very conveniently with low noises, slight vibration, lightweight and simple construction.
Picture of the production line
MYT SERIES Technical Data
| Model | Power | Voltage(V) | Frequency (HZ) | Current (A) | Power Factor | Eff(%) | Speed (r/min) | Tstart/Tn | Tmax/Tn | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| HP | KW | ||||||||||
| MYT711-2 | 0.75 | 0.55 | 220 | 50 | 3.88 | 0.92 | 70 | 2800 | 0.35 | 1.7 | |
| MYT712-2 | 1 | 0.75 | 220 | 50 | 5.15 | 0.92 | 72 | 2800 | 0.35 | 1.7 | |
| MYT801-2 | 1.5 | 1.1 | 220 | 50 | 7.02 | 0.95 | 75 | 2800 | 0.33 | 1.7 | |
| MYT802-2 | 2 | 1.5 | 220 | 50 | 9.44 | 0.95 | 76 | 2800 | 0.33 | 1.7 | |
