Payment & Shipping Terms
Price Quote	Negotiation
Minimum Order	10pcs
Average Delivery Time	25days
Payment Method	TT, westerm union,Credit cards,Alipay
Package Details	Carton or veneer case
Ability to Supply	60000pcs per month

Technical Characteristics
Products	HS Hollow Shaft Motor
Output Range	0.5HP-30HP
Application	High pressure washer
Standard	IEC 60034-1
Phase	Three phase
Insulation Class	F
Degree of Protection	IP55
Service Factor	1.00
Temperature Rise	80 K
Ambient temperature	-15℃≤θ≤40℃
Mounting	75/90mm, 87/61mm
Frame Material	Aluminum
Standard Bearing Brand	C&U

ASYNCHRONOUS HOLLOW SHAFT MOTORS

The direct coupling between the motor and high-pressure pump, ideal for pressure cleaners and washing plants, significantly reduces the machine’s overall size and provides a reliable and cost-efficient solution. We have a wide range of flanges and shafts suitable for direct coupling with most of the pumps on the market today.

Application Picture

Picture of the production line

HS SERIES Technical Data

THREE-PHASE 2 POLES 3000RPm 50Hz

FRAME	POWER		RPM	COS¦Õ	EFF.%	VOLT	AMPERE
	KW	HP		P.F.		V	A
711-2	0.37	0.5	2780	0.82	82	400	0.8
712-2	0.55	0.75	2790	0.83	81	400	1.2
90L1-2	2.2	3	2820	0.86	78	400	4.9
90L2-2	3	4	2820	0.86	78	400	6.6
90L3-2	3.7	5	2820	0.80	83	400	8.6
100L1-2	3	4	2840	0.83	81	400	7
100L2-2	4	5.5	2850	0.86	82	400	8.5
100M1-2	4	5.5	2830	0.84	82	400	9.4
112M2-2	5.5	7.5	2840	0.85	83	400	11.7
132S1-2	5.5	7.5	2890	0.86	84	400	11.6
132S2-2	7.5	10	2900	0.86	84	400	15.4
132M1-2	11	15	2920	0.88	86	400	21.8
132M2-2	15	20	2920	0.88	86	400	29.3
160M1-2	15	20	2920	0.87	88	400	28
160M2-2	18.5	25	2920	0.87	89	400	34
160M3-2	22	30	2920	0.87	89.2	400	41

THREE-PHASE 4 POLES 1500RPm 50Hz

FRAME	POWER		RPM	COS¦Õ	EFF.%	VOLT	AMPERE
	KW	HP		P.F.		V	A
711-4	0.25	0.35	1370	0.73	64	400	0.8
712-4	0.37	0.5	1350	0.74	68	400	1.1
713-4	0.55	0.75	1350	0.75	66	400	1.6
90L1-4	1.5	2	1400	0.82	78	400	3.4
90L2-4	2.2	3	1400	0.79	77	400	5.4
90L3-4	2.6	3.5	1400	0.80	78	400	7.4
100L1-4	2.2	3	1400	0.80	81	400	5.1
100L2-4	3	4	1410	0.80	81	400	6.9
100L3-4	4	5.5	1420	0.80	82	400	9.4
100M1-4	4.4	6	1420	0.82	83	400	10
112M1-4	4	5.5	1420	0.80	83	400	9
112M2-4	5.5	7.5	1430	0.82	84	400	12.1
112M3-4	6.2	8.5	1425	0.82	84	400	13.5
112L-4	7	9.5	1430	0.80	85	400	13.8
132S1-4	5.5	7.5	1430	0.82	84	400	11.7
132S2-4	7.5	10	1430	0.84	84	400	15.4
132M1-4	9.2	12.5	1430	0.90	85	400	17.8
132M2-4	11	15	1430	0.90	87	400	21.3
132M3-4	12.5	17	1430	0.88	84	400	26
160M1-4	15	20	1450	0.86	89	400	29
160M2-4	18.5	25	1450	0.86	90	400	34

THREE-PHASE 6 POLES 1500RPm 50Hz

FRAME	POWER		RPM	COS¦Õ	EFF.%	VOLT	AMPERE
	KW	HP		P.F.		V	A
71-6	0.25	0.35	880	0.73	45	400	1.1
90L-6	1.1	1.5	910	0.72	72	400	3.2
100L-6	1.5	2	910	0.80	74	400	3.9
112M1-6	2.2	3	940	0.80	80	400	5
112M2-6	3	4	940	8	79	400	6.9
132S1-6	3	4	940	0.78	80	400	6.9
132S2-6	4	5.5	950	0.79	82	400	9
132M1-6	5.5	7.5	950	0.79	83	400	12.4
132M2-6	7.5	10	950	0.79	83	400	16.5
160M1-6	7.5	10	960	0.77	87	400	16.5
160M2-6	11	15	960	0.79	88	400	23

SINGLE-PHASE 2 POLES 3000RPm 50Hz

FRAME	POWER		RPM	COS¦Õ	EFF.%	VOLT	AMPERE
	KW	HP		P.F.		V	A
711-2	0.5	0.37	2790	0.95	62	230	2.7
712-2	0.75	0.55	2790	0.98	61	230	4
90L1-2	2.5	1.8	2850	0.95	65	230	12.7
90L2-2	3	2.2	2840	0.99	72	400	13.4
100L2	3	2.2	2850	0.96	74	400	15.3

SINGLE-PHASE 4 POLES 3000RPm 50Hz

FRAME	POWER		RPM	COS¦Õ	EFF.%	VOLT	AMPERE
	KW	HP		P.F.		V	A
711-4	0.35	0.35	1360	0.91	57	230	2.1
712-4	0.5	0.37	1380	0.94	65	230	2.6
90L1-4	2	1.5	1400	0.98	70	230	9.5
100L1-4	2.5	1.85	1390	0.97	68	230	12.2
100L2-4	3	2.2	1350	0.99	74	230	13.1
100L3-4	3.5	2.6	1350	0.96	74	230	17.5
112M1-4	4	3	1400	0.98	74	230	18.1
112M2-4	5	3.7	1410	0.96	76	230	22

Installation   Dimensions

FRAME	Flange size			Frame size
	M	N	S	A	AC	B	H	HC	L	K
71	75	90	7	112	180	90	71	184	217	7
90L	75/87	90/61	7	140	238	125	90	22	270	9.5
100L	75/87	90/61	9	160	255	140	100	240	315	11
112M	75/87	90/61	9	216	326	140	132	265	330	11
132S	75/87	90/61	9	216	326	140	132	320	370	12
132M	75/87	90/61	9	216	326	178	132	320	409	12
160M	97	Mar-00	9	254	360	210	160	410	498	14.5
